Model 912 Sewage Package System

Product Details

The Zoeller Model 912 Sewage Pump Package System is engineered to deliver a reliable, job‑ready solution for sewage ejector applications where plumbing fixtures are located below the existing sewer line. Designed for residential and light commercial installations, the Model 912 ships factory assembled to reduce labor time and improve installation consistency.

Each Model 912 system is available in simplex or duplex configurations using 4/10 HP or 1/2 HP automatic sewage ejector pumps. Automatic operation is provided by either snap‑action (integral) float switches or piggyback mechanical float switches, depending on the pump model selected. Duplex systems incorporate alternator controls that balance run time between pumps to extend service life.

The standard package includes a 24″ × 24″ poly basin with 41‑gallon capacity, optimized for shallow burial and indoor installations. To accommodate deeper or outdoor installations, the system supports approved basin extensions and risers, as well as 18″ × 30″ basin configurations using compatible PSF or fiberglass basin components.

Installation‑focused enhancements include a removable float tree, molded torque stops, and an anti‑flotation device to help secure the system once installed. The 24″ x 24″ basins include a clear construction cover that is shipped with each package to protect internal components during rough‑in and masonry work.

Optional high‑water alarms and Wi‑Fi‑enabled monitoring solutions, are available to enhance system protection and notification. Each Model 912 package is 100% factory tested prior to shipment, ensuring dependable performance out of the box.

Features and Benefits

• Factory‑assembled sewage ejector package minimizes installation time and reduces field‑assembly errors
• Available with 4/10 HP or 1/2 HP sewage ejector pumps in simplex or duplex arrangements
• Automatic pump options include: Snap‑action (integral) float switches, or Piggyback mechanical float switches, depending on pump model and configuration
• Basin configurations can be adapted using approved extensions and risers, including: 24″ × 24″ basin extensions for deeper indoor or outdoor installations or 18″ × 30″ basin options using approved PSF or fiberglass basin components
• Equipped with 2″ discharge connections, suitable for residential and light commercial sewage piping systems
• Compatible with optional high‑water alarms, including self‑testing and Wi‑Fi‑enabled monitoring, and alternator controls for duplex systems
• 3-year limited warranty: this model comes with warranty coverage from Zoeller Pump Company, giving you extra protection and more peace of mind
